Microstructure Modeling with OOF2 and OOF3D

2022.07.27 Stephen Langer & Andrew Reid, NIST OOF2 can be run at: https://nanohub.org/tools/oof2 OOF3D can be run at: https://nanohub.org/tools/oof3d Table of contents below. The OOF object-oriented finite element software, developed at the National Institute of Standards and Technology, provides an interactive FEM tool which packages sophisticated mathematical capabilities with a user-interface that speaks the language of materials science. Users can assign material properties to the constituent phases of a microstructural image, and then construct finite-element meshes from these images, in either 2D or 3D. The tool then allows users to perform virtual experiments using a variety of boundary conditions to explore structure-property relationships within the system, including effective properties. Table of Contents: 00:00 Microstructure Modeling with OOF2 and OOF3D 00:51 What? 01:55 OOF2 Conceptual Ingredients 03:00 Basic Steps 03:33 Physics 04:48 Units 05:10 2D vs. 3D 06:06 OOF3D 07:08 Demo 10:14 FAQ: Why is the graphics window empty? 11:06 Demo 22:26 Data File Formats 23:49 Demo 28:31 Skeleton Quality Measures 30:10 Demo 33:06 Don't over-refine a Skeleton 34:59 Demo 41:58 Terminology for Fields and Equations 42:42 Demo 52:48 FAQ: Computing effective moduli 54:43 Topics that we've skipped… 55:41 For more information 57:48 Demo 59:12 For more information 62:51 Demo 63:55 For more information This presentation and related downloads can be found at: https://nanohub.org/resources/36380
