Elscint vibratory feeder for feeding Bullet Cartridges Elscint recently supplied a customer with 2 bowl feeders for feeding of blanks of bullet cartridges. Both the bowl feeders were Model 400 with a dia 750 mm big bowl. The requirement was to feed bullet cartridges in multiple rows. One side of the brass cartridge was open while the other side was closed. The requirement was to feed the same with the closed side forward. A variety of cartridge blanks were to be fed in the same bowl, varying from dia 10 mm to dia 16.50 mm and length varying from 27 mm to 50 mm. Four outlets were required for each of these bowl feeders making the same complicated, especially due to the variety of cartridges to be fed in the same bowl. e open end of the cartridges were uneven, making the orientation further difficult. Having multiple rows with such orientation is always a challenge and Elscint provided easy changeover tooling for the same. The changeover took just 2 minutes. Outlet in all these cases was given in flexible tubes which the customer could attach to his press where the parts were fed for further drawing. Elscint used its Model 400 with a cast aluminium bowl with Elscinthane polyurethane coating for this application. You can watch the video of the equipment.
