JX-2.2 high shear batch mixer with lifting system

https://ginhong.com/high-shear-mixer/... JX batch high shear homogenizer is a top entry high shear mixer for the production of viscous cream and emulsions in the cosmetic, pharmaceutical, food and chemical industries. It’s usually used in a multi shaft mixer for homogenization. Key Features Working capacity from 1.5kw to 55kw; Suitable for cream and emulsions of 20,000~80,000cps viscosity; Suitable for batch process with high efficiency; Pneumatic or hydraulic lifting system for easy cleaning and maintenance; Complete process of dispersing, high shearing, emulsifying and homogenizing; Work with different mixing tanks; All contact parts are made of SS304/316L and mirror polished; The specifications of the top entry batch mixer comply with cGMP regulations; Power supply of 380V, 50Hz, 3 Phase; Technical Specifications Model Motor power (kw) Speed (rpm) Handling Capacity (L) JX-1.5 1.5 3000 30~50 JX-2.2 2.2 3000 50~100 JX-3 3 3000 50~200 JX-4 4 3000 100~300 JX-5.5 5.5 3000 200~600 JX-7.5 7.5 3000 300~800 JX-11 11 3000 400~1000 JX-15 15 3000 500~1500 JX-18.5 18.5 3000 600~2000 JX-22 22 3000 800~2500 JX-30 30 3000 1000~3000 JX-37 37 3000 1500~4000 JX-45 45 1500 2000~5000 JX-55 55 1500 3000~6000 General Applications Cosmetics & Toiletries: cream, lotion, wax, mascara, gel, toothpaste; Pharmaceuticals: ointment, dental composite, syrup, injection; Food: mayonnaise, dressing, jam, butter, margarine, wasabi; Chemicals: polyester, synthetic fiber, shoe cream; Mixer Options Atmospheric or vacuum design available for different applications; Interchangeable work heads and screens of slotted and holed designs; Circular and rectangular flange designs for mounting on the vessel; Different combinations of batch mixer, agitator, high speed disperser and inline mixer for different mixing processes Adjustable brackets for holding the manufacturing tank tightly; Control panel with variable speed drive for adjusting mixing speed; Explosion proof motors and electrics; Different power supply acceptable; Different pneumatic, hydraulic and electrical lifting devices for lifting the batch mixer for exchangeable tanks; If you want to learn more about our JX-2.2 high shear batch mixer, please feel free to contact me. YouTube:    / @ginhongmixer   Facebook:   / lukewhb   LinkedIn:   / ginhong   WeChat: lukewhb WhatsApp: +86-189 5126 2589 Email: info@ginhong.com Website: https://ginhong.com
