BM-22AD Turret Milling Machine HAFCO Metalmaster (M593D)

http://www.machineryhouse.com.au/M595D BM-22AD Turret Milling Machine HAFCO Metalmaster (M593D) Features 3-Axis digital readout counter fitted with 2-Axis X & Y scales only 3hp, 240V motor, 8-speeds V-belt drive system NT30 Spindle taper with a chrome & ground quill Hardened & ground work table & slide-ways All slides utilise dovetail construction for maximum rigidity Meehanite casting for high strength & minimal deformation Quality electrics & overload protection in an easy access enclosure Horizontal travelling ram mounted on a rotating base allowing re-positioning of spindle The ram incorporates a tail lug (spigot) to accept a slotting attachment etc. High / neutral and low gear selection lever to maximise torque Asong X-Axis power-feed with adjustable micro switch feed stops Metric dial graduations @ 0.02mm for X , Y & Z-Axis Automatic quill feed 0.04, 0.08, 0.15mm/rev Automatic cut off depth stop on quill Oil lubrication pump and reservoir Slideway covers Y & Z-Axis Mill head tilts to ±45º forward and back Mill head tilts to ±90º left and right Coolant system with flexible hose Manual quick action quill lever Mechanical spindle brake Tool box and manual Includes 3-Axis digital readout counter fitted with X & Y scales only One-shot oil lubrication pump and reservoir Drawbar M12 thread Coolant system Slideway covers X-Axis power-feed Halogen light Safety cutter guard Swarf tray ORDER CODE: M593D Model: BM-22AD Digital Readout: 2-Axis Digital Readout Type: Vertical Table Size: 1066 x 230mm Spindle Taper - Vertical: NT30 Longitudinal Travel (X-Axis): 590mm Cross Travel (Y-Axis): 295mm Vertical Travel (Z-Axis): 380mm Type of Slides: Dovetail Ram Travel: 500mm Quill Travel / Diameter: 127mm / 85mm Throat Depth (max.): 720mm Tilting Head (Left ~ Right): ±90º Tilting Head (Forward ~ Back): ±45º Power Feed - Quill: 0.04, 0.08, 0.15mm/rev Power Feed - Longitudinal (X-Axis): 20 - 2000 mm/min Power Feed - Cross (Y-Axis): Optional Power Feed - Vertical (Z-Axis): Optional Table T-Slot Size: 16mm Work Table Load Capacity: 250kg Spindle Speeds Vertical (steps/rpm): 8 (80-2760rpm) Motor Power - Vertical: 2.2kW / 3hp Motor Voltage: 240V - 15amp Overall Height: 2150mm Weight (nett): 1100kg For more information on this machine, please visit: Hare and Forbes Machineryhouse Sydney: (02) 9890 9111 Melbourne: (03) 9212 4422 Brisbane: (07) 3715 2200 Perth: (08) 9373 9999 http://www.machineryhouse.com.au/M593D Machineryhouse - NZ Auckland: (09) 2717 234 http://www.machineryhouse.co.nz/M593D
