The New R.U.L.E Module. Dev #1

You probably noticed I have changed the name of the module, R.U.L.E. (Reactive Universal Logic Engine) seems to be more suitable. The focus is, after all, on rules the user creates to control flow and activities. There are a lot of other features that add to the "Rules Block" and can directly be used in real time. The sample rate will improve drastically so CV's can be audio rate if need be. Here's a fun little sequence of Rules: Random-but-repeatable CV sequence IF GT.B = HIGH ;gate high is enable, drop to low is reseed IF TR.A↑ IF BUS5 = 0 OUTB = BUS1 ELSE BUS5 = 1 OUTB = BUS2 ELSE BUS5 = 2 OUTB = BUS3 ELSE OUTB = BUS4 ENDIF BUS5 = BUS5 + 1 IF BUS5 (is greater than)= 4 BUS5 = 0 ENDIF ENDIF ELSE BUS1 = RND1 BUS2 = RND2 BUS3 = RND3 BUS4 = RND4 BUS5 = 0 ENDIF This will generate a random sequence when jack B is low, then play a repeating sequence at the clock rate on jack A when jack B is high. 23 lines.
