ACM Processing on Ranger 6321

Tecnology Muratori Machines: RANGER 6321 + Double Loader Material: ACM Processing: Autoloading, autofeeding, hi speed Vgroove, routing Task requested by the Prospect: Autoloading, high speed VGroove on complicated cassettes Sectors: construction, architectural facades, cladding The customer is concerned about the cost of personnel for low value-added operations such as loading and positioning the panel in the machine. In addition, the size and weight of the architectural panels requires the use of several people (up to 5/6) for loading and alignment operations in the machine. Furthermore, there is an increasing demand for complex box shapes that require V-Groove milling with different angles. Therefore, they are asking for the possibility of performing high-speed V-Groove milling at any angle requested by the facade designers. Obviously, if it were possible to perform it at high speed and with a high finish, the Ranger solution would be indispensable. Focus on/Highlights - ENG: ⁃Speed of execution (10 m/1' – ca 395 IPM) of VGrooving aggregate with different angles ⁃Cut finish on the edge ⁃Cleanliness of the work surface and work area ⁃Chip containment (high suction performance) ⁃Work ergonomics ___________________ Watch the Ranger CNC dramatically simplify labor-intensive panel handling. This innovative router reduces manual effort, enhances operator safety, and significantly improves both productivity and ergonomics. SPACE SAVING: 60% Because they are vertical, our CNCs Ranger take up 60% less space, compared to a horizontal machining centre with the same worktable surface area. Safety The vertical worktable, the side guards and the photoelectric cells fitted on the Panel Router guarantee a high level of safety for the operator. Cleaning of the table Thanks to the verticality of the worktable, the shavings produced and not sucked up during the process fall to the floor, leaving the surfaces perfectly clean, thereby preserving the integrity of the panels. Large panels workable The height and solidity of the base, and the flatness of the vertical structure, ensure that large panels can be processed while occupying the least possible space. Ergonomics The verticality of the Panel Router table and its automation in loading and offloading operations make the work more ergonomic for operators, whilst also reducing the risk of panels falling. Discover more: https://muratorimachines.com/en/machi... _____________ Why Double Loader is called “double”. This machine has been conceived in 2021 when a French customer said that his warehouse had half of the ACM panels with the good face up and half with the good face down (the good face is the one covered by the protective film). Our Alu Loader Patented in 2011 could only handle the ACM with the good face up. Therefore we designed and build an arm that can articulate in order to lift a panel or flip a panel depending on how the pallet has been oriented. Discover more: https://muratorimachines.com/en/machi... _____________ How old is Loader and why it is so important to the Ranger Loader has been conceived in 2010 and patented in 2011 when it was very clear that loading ACM panels was required into the market. With long and wavy ACM panels the Loader has gained lots of customers happy to load without hassles. After few months customers asked for more capacity of loading and Loader became able to load also “heavy” panels such as HPL fibercement or solid aluminum panels. Discover more: https://muratorimachines.com/en/machi... ______________ What is Alu Bender? A milling and bending machine for different kind of panels mostly used in architectural facades industry. Originally made for ACM (aluminum composite material), Alu Bender can process the edges of Alu honeycomb panels, HPL and fibercement. In ACM and honeycomb panels the process consists of milling off the undesired material (normally the back face or skin) and then bending the fin remained to cover the edge determining the hemming. This process allows a higher protection for the edges but also improves the quality overall of the panel. With a similar process but with different tooling the aluminum honeycomb panels are milled and bend in order to close the edges and protect the 4 sides. HPL has s slightly different concept. When cut by saw blades the edge is full of chatter marks and also there is a need of bevel both top and bottom of the edge. Alu Bender simply removes few decimals of material flattening the edge and removing the chatter marks. After that process a second unit with two independent HF motors bevels or makes a radius on both top and bottom, IN THE SAME PASS. Same thing applies to fibercement except for the auto application of Luko liquid for water resisting edges. Discover more: https://muratorimachines.com/en/machi...
