How to change units in AutoCAD 2025 | How to set Dimension unit in AutoCAD

In AutoCAD, we can set units by two methods, 1) First Method Type ‘UNIT’ in the command bar and press the Enter key. By pressing the Enter key, we will see one dialogue box. From this dialogue box, we can set units as required. 2) In a second Method Go to the ‘Application menu’ at the top left corner of the AutoCAD workspace screen and select the ‘Drawing utilities‘ option. From the Drawing utility option, we have to select the ‘Units’ option. By selecting the units option, one dialogue box will open. From this dialogue box, we can set units as per requirement. Now, we will see the details of the ‘Unit’ dialogue box. AutoCAD provides us a facility to set units for length and angle separately. Select type and precision of unit as your requirement. Length Unit Types are as below 1) Architectural 2) Decimal 3) Engineering 4) Fractional 5) Scientific 1) Architectural Architectural units are based on feet and inches. Select the proper precision as you want. The base unit is the inch unless otherwise specified and this unit shows frictional units, so if you enter a number like 145.5, then AutoCAD will understand it to be 12′1 1/2″. Also, change the ‘Insertion unit’ in inches or feet from millimeters. 2) Decimal Decimal units are unitless. They are not based on any particular unit. We can set millimeters, meters, centimeters, or any suitable units in decimal. Also, set ‘Insertion unit’ as required. An example is 10.5. 3) Engineering Engineering units are the same as architectural units. It is also based on inches and feet unit but it represents partial inches like 12’1.5”. Set precision as required. Also, change the ‘Insertion unit’ in inches or feet frommillimeters. 4) Fractional Fractional units are unitless the same as decimal units. But fractional units show values as fractional rather than decimals like 10 ½. 5) Scientific Scientific units, also unit less and show values as exponents. This unit shows units the same as a scientific calculator. These units are used for a really very tiny or very big drawing. If you design molecules or galaxy, this is a useful unit for you. Example would be 10.2E+06 (which is 10,200,000) or 10.2E-06 (which is 0.0000102) Angle Unit Types are as below 1) Decimal Degrees 2) Deg/Min/Sec 3) Grads 4) Radians 5) Surveyor’s unit 1) Decimal Degrees Decimal degree units are showing decimal numbers. By doing work with this unit is easiest if allowed in your project. It shows numbers like 10.5 the same as the length decimal unit. 2) Deg/Min/Sec Deg/Min/Sec is based on dividing a degree into minutes and minutes into seconds. Seconds are not fine enough to display AutoCAD’s precision capabilities, so seconds can be further divided into decimals. There is no degree symbol on the standard keyboard, so AutoCAD uses the lowercase letter d. An example would be 40d30′10.724″. 3) Grads Grads are also called Gradient. This is a mathematical unit. Mathematically, 90 degrees angle=100 grads. So we can say that a total of 400 grades are available in one circle. We can give a 45-degree angle by giving 50 grades. Also set precision as per requirement. 4) Radians Radians are also mathematical units. #HowtosetunitinAutocad2025 #HowtosetmminAutocad #HowtosetDimensionunitinAutocad #howtochangeunitsinautocad
