Flap Barrier Turnstile Gate Instalaltion and Commissioning | Shining Flap Barrier | Turnstile Gate

Hello! Guys we here we are installing the Shining Flap Barrier Turnstile gate and its Integration with the FALCO Controller. Flap bariier controlled by the RF Reader through Falco Access Control System. Installation | Integration | Wiring | Commissioning | FALCO CONTROLLER | FALCO TURNSTILE | SHINING TURNSTILE GATES. Smart gate automation and Configuration with the Access Control Database and Visitor Management System. Smart Gate | Smart Flap Barrier | Turnstile Gates | Boom Barriers | Gate Automation and More. ✅ Connection Digarm Explanation 👇 ❍ FALCO Controller Side ----------------) FALCO RF Reader side ➥ +12V----------) +12V (red wire ) for VCC ➥ 0V ----------) 0V (Black Wire) for GND ➥ D1 ----------) D1 ( White Wire) for Wiegand D1 ➥ D0 ----------) D0 ( Green Wire) for Wiegand D0 ➥ L1 ----------) L1 ( Grey Wire) for LED ➥ BZ ----------) BZ ( Purple Wire) for Bipper\Buzzer ❍ FALCO Controller Side ----------------) Shining Turnstile Side (In this section You can assume as your site position as Right Turn\Left Turn or Exit\Entry 👇) ➥ C2 -------------------------) OP L (Open Left) EXIT ➥ 02 -------------------------) COM ➥ C1 -------------------------) OP R (Open Right) Entry ➥ 01 -------------------------) COM ❍ RJ-45 COLOUR CODE (Type B) ➥ 1 WHITE-ORANGE -------------------------) Rcv Data+ ➥ 2 ORANGE ------------------------) Rcv Data ➥ 3 WHITE-GREEN -------------------------) Tx Data + ➥ 4 BLUE BLUE -------------------------) DC+ ➥ 5 WHITE-BLUE -------------------------) DC+ ➥ 6 GREEN ------------------------) Tx Data ➥ 7 WHITE-BROWN ------------------------) DC ➥ 8 BROWN ------------------------) DC ❤️ 𝗦𝘂𝗽𝗽𝗼𝗿𝘁 𝗠𝘆 𝗬𝗼𝘂𝗧𝘂𝗯𝗲 𝗖𝗵𝗮𝗻𝗻𝗲𝗹: https://cutt.ly/om4JVb1 & Finally Bundles of Thanks to all my SUBSCRIBERS and Viewers. 𝗧𝗵𝗮𝗻𝗸 𝗬𝗼𝘂 for stopping by, and I hope to see you again soon! Please like, share and subscribe to my channel if you like what I do. ❤️ Enjoy & stay connected with us! ►► For business enquiries👇 What'sAPP/IMO/Viber:- 9860042974 ➥ Subscribe HERE ❍ https://bit.ly/2NVd1uD ❤️ Stay connected : 🔔️️️Follow Me On Instagram:   / lakparinji   🔔️️️Follow Me On Twitter:   / lakparinji   🔔️️️Like Our FB Page:   / lakparinji   About : Lakparinji is a YouTube Channel, where you will find technological videos Weekely:) ⊂(◉‿◉)つ⊂(◉‿◉)つ⊂(◉‿◉)つ ＬＩＫＥ || ＳＨＡＲＥ ||ＣＯＭＭＥＮＴ || ＳＵＢＳＣＲＩＢＥ ©LAKPARINJI
