PIFA Optimization overview with HFSS and optiSLang

0:00​ PIFA 3D model in HFSS 1:11​ ACT - HFSS optiSLang linking usage 2:12​ ​optiSLang setting about derivative analyzing 6:35​ Results 7:08​ All result data reviewable in the HFSS The derivative-based optimizer extends the current optimization capabilities found in HFSS and optiSLang. The optimization is setup using an ACT Extension in the Ansys Electronics Desktop and a custom optimization algorithm in optiSLang. This workshop showcases the derivative based optimizer to optimize a planar inverted F antenna (PIFA) design The current PIFA design resonates at 2.3 GHz. The optimization goal is to modify Length1 and Length2, so that the antenna resonates at 2.44 GHz. Minimize return loss at 2.44 GHz This workshop and derivative based optimizer was created for HFSS 2021R1 and optiSLang 2021R1
