How-To Debug Calibre® PERC™ P2P Resistance Violations Through Path Segmentation

The Calibre interactive P2P GUI enables design teams to interactively set up and run coordinate-based Calibre® PERC™ P2P simulation runs, making it an effective debug tool for rule-based P2P violations. Designers can quickly and easily place source and sink probe points in a layout, simplifying and speeding up net segmentation and targeted P2P simulations. This simple, fast, and effective solution provided by the Calibre RVE interactive P2P GUI gives IC designers the data they need to accurately reduce parasitic effective resistance while eliminating traditional time-consuming P2P simulation runs. The ease of use combined with the speed and accuracy of the results make the Calibre interactive P2P GUI an effective option for improving the productivity and ease of use of the IC reliability verification flow. This video tutorial walks users through an example of how to segment a P2P result net into smaller resistances in order to identify which portion of the path is contributing most to the total effective resistance.
