3709 = 1 - 2 = Deckel Maho DMU 80 P Hi Dyn 5 Axis machining centre HeidenHain MILLPLUS

DMG 5 Axis 80 P Hi DYN Make : Deckel Maho Germany Type : DMU 80 P Hi-Dyn Mach. No : Age : 2005 Capacity / Working area X - Travel : 800 Y - Travel : 700 Z - Travel : 600 Table Ø : 630 Table load Kg : 600 Rapid speed rotary : 9.3 Rpm Rapid speed swivel : 7.3 Rpm Rotation speed : 360 x 0.001 Gr Swivel angle : – 45 to + 30 Gr Spindle taper : ISO 50 Spindle power : 16 kW Spindle speeds : 6.300 Rpm Feed rate : 60 M/Min Rapid rate : 60 M/Min ATC Changer : 30 Positions Tool Ø 230 x 350 x 20 Kg Change time : 6.5 sec Heidenhain MILLPLUS in 5 Axis Heidenhain Glass scales input : 0.001 mm Heidenhain Rotary encoder input : 0.001 mm Chip conveyor Coolant system 600 Liter Pressure 40 bar BLUM laser tool Renishaw MP 10 touch probe Automatic swivel head HOR & VERT Dimensions Length : 5.000 Width : 3.000 Height : 3.100 Weight : 9.000 Please Note: The above information has been obtained to the best of our ability and belief from, and from the manufacturers where possible. It is given in good faith, but its accuracy can not be guaranteed. Accordingly, it will not form a representation or constitute contractual terms. We advise you to check any vital details!
