How to replace a Timing Belt on Toyota LandCruiser 1HZ & 1HD-T Engines

Hey Guys and Gals! In this video i show you how to replace the timing belt on your Toyota Landcruiser 80 series, 105 series, 70 series with the 1HZ or 1HD-T engines. I talk you through the process of replacing the timing belt and tensioning roller bearing. There are two pulleys that need to be aligned and one tensioner pulley. You will need to remove the power steering res & the timing cover. Then you can rotate the engine by the crank bolt until the timing marks align. I use a paint pen to highlight the timing marks and make it very easy to see. You can then remove the tensioner bolts and remove the tensioner completely. Then the belt will easily be able to be pulled off the pulleys. After cleaning down the area with brake cleaner i began the reassembly. Firstly fit the Tensioner Pulley and loosely do up the bolts about finger tight but so the tensioner pulley can move up and down freely. Then you can fit the timing belt to the pulleys, ensure that the slack in the belt is on the tensioner side and on the other side the belt is rather tight with no play. Then it is time to fit the tensioning spring, after this is fitted check the tension on the belt and tighten the tensioner bolts. Rotate the engine over twice untill your timing marks realign and check that all the marks are exactly aligned before fitting the timing cover. Not your ready to fit the power steering resivour and the timing belt replacement sticker. Then start your vehicle and ensure everything is running ok! It is a rather easy process and once you have done it once you will get better and quicker at working with engine timing each time you do such jobs. I hope this helps you guys in replacing your timing belt on your 1HZ and 1HD-T engines. If it did help you, please support my channel by liking and SUBSCRIBING to my channel :D Thanks alot guys and gals! Cheers, Nick The awesome music at the end is thanks to : Last Summer by Ikson:   / ikson   Music promoted by Audio Library    • Last Summer – Ikson (No Copyright Music)
