Maximum current limit Growatt SPF5000ES

3 strings x 6 pv pannels JaSolar 595Wp in parallel connected to mppt input on Growatt SPF5000ES. The mppt itself have automatic current limit to 22A but do not have automatic limit on the input voltage so be careful DO NOT ADD more than 8 panels JaSolar 595Wp in series (400-410V max at open circuit) If you want more power you can add more parallel strings. If you add more than 8 pannels 450+ you have high risk of burning the mppt. For the parallel strings you can add many and inverter will handle it. Also keep the inveroment cool, not above 28-30 degrees celsium! 21-22 C° is perfect. I am using airconditioner. FOR GROWATT SPF6000ES you can and maximum 9 in series and also many in parallel!
