CNC Table Legs

Turning a project on the Recoil axis. This is a time laps of turning a project on the A-axis with Vectric Aspire 8.5 software. I wrap the A to the X axis. This is Z-Zero at the center of the material. Walnut blank, started out at almost 25" long and about 8" dia. 3 Bits are used, 3/8" compression for clearing, 1/8" ball nose at 8% step over, and 1/2" for the end milling at 3" down. While this could have been done on a Lathe, the objective was to design a part and then be able to duplicate it as many times as wanted without the need for other equipment. This was not about speed but a project on the CNC Rotary axis. When doing the project I did find an error in the Post Processor, with the help of the PP master it was updated and the ATC with Rotary was going good. Post Processors are always machine specific. Two legs made for the project. Free music track provide by : www.bensound.com
