How to Export SketchUp File to SolidWorks (English) - Advanced Full Method - sketchup to solidworks скачать в хорошем качестве

How to Export SketchUp File to SolidWorks (English) - Advanced Full Method - sketchup to solidworks

sketchup to solidworks ================= ================= DO NOT CLICK HERE: http://bit.ly/projetos_infinity ================= ================= Setting up my PC to use Solidworks⤵️ Xeon Processor https://amzn.to/3Owfuvk GPU Rtx 3000 https://amzn.to/3DrE0aD ssd 256gb https://amzn.to/3Q7QZWo RAM ddr4 32gb https://amzn.to/3q3jR7w Wireless mouse https://amzn.to/44VnAmg 3D mouse https://amzn.to/44VnLxW foldable wireless keyboard https://amzn.to/3Y4T8UN Monitor 22" https://amzn.to/3rIo0hR Dell i7 laptop https://amzn.to/477VEgU download my grabcad projects including this video man https://enrt.eu/download_grabcad_proj... sketchup extension STL https://enrt.eu/extension_stl_sketchup hello my student, student of infinity projetos brasil, i am the tlm engineer teacher, and in this video i will teach you how to export from sketchup to solidworks after opening the downloaded file we will use the rectangle tool, this tool will be used to create two overlapping rectangles man, so we will divide the file into three parts, it is important to do this to make the file lighter, if you have a good computer, this step is not necessary, skip to export step made the rectangle, select it and click the move button, to move the rectangle approximately in the third part of man now we click on the select tool and copy the rectangle to have another dividing the first part of the second, so having three separate parts done, let's close the file and generate 3 copies of it, for later we can do the division now we open the first file and delete one of the rectangles, click on the rectangle what's left and we click the push tool, now we drag the rectangle upwards generating a kind of extrusion, click the select button select the whole cube right click on the cube and click create group with the selected cube click edit then click intersect faces then click with model then just click on man this will intersect on man exactly where the cube passes now click on the cube and delete it now click on the human with the right mouse button then left click on unlink, then just click on the top of the person and hit delete, this way we take the top off now we save the file, and we do the same process for the other two parts, so we have the bottom, separated intermediate and upper now we will download a stl export skethup extension, click on the video description link and then install to install we will have to open sk etchup and click window, then preferences, then in the window that will open click extensions and install extensions, look for the downloaded executable file and click open, click yes and then ok, now we see that we already have the option to export In stl in this video I will teach you how to open a sketchup file in solidworks, first we will download any file from the sketchup site for later opening in solidworks, in this example we will download a chair, after downloaded we will have to download the sketup stl extension from the site that is In the video description, after installing this extension, we will transform the open file (chair) in stl format, because this is where we will open in solidworks, except the file in stl, we will open solidworks to transform into solid file, for that we have we change it down to stl format, and then click on options, done that we will choose the surface body option, we click ok and ok again. let's now export the three parts of man to stl by opening one by one and exporting, for that click file, then click export stl, then put the unit as millimeters and click export, and save the stl file, let's do that for the three parts let's go to the open part in SolidWorks, find the location of the stl files, click all files then choose stl, click the first file then click options, now leave it selected as a surface body, this will make the file possible be edited, ie stay as multiple surfaces drawn, change to millimeters and click ok, and open the file open the file let's save it and do the same process for the other two parts let's now create a new assembly file and insert the 3 parts of the person now we will assemble the 3 parts using the technique of the same planes, because when we exported them the origins of the three xyez axes, they kept the same ones, so just place a one-piece plane positioning constraint to the same one. another, doing it for the three planes and it is fully assembled to our person let's look at what it was like in sketchup and what it looked like in SolidWorks, see that in infinity projects brazil export from sketchup to inventor export from sketchup to solidworks export from sketchup to catia export from sketchup to solid edge How to Import Sketchup files to SolidWorks? How to Import Sketchup files to SolidWorks how to work sketch up file into solidworks how to export sketch up files to solidworks #solidworks #infinityprojetosbrasil #sketchup
