DIY pinball part 3 - Inserts

A pinball insert (table roll over switch) Using cheap SS49E hall effect sensors and neodymium magnets. STL's & Fusion360 project can be found here: https://www.thingiverse.com/thing:264... All parts printed in PLA. The clear lens in PLA transparent. For testing i printed a large apron around the sensor so i could roll the ball across the sensor. In the final design i would only print the lens to fit within the sensor case. The single LED will probably be replaced with 3xAPA102 LED's...for blinky colorful goodness. It's not the easiest way to make a switch but it won't alter the balls trajectory and it's completely reliable. I may or may not include this in the final design. Parts used... 3x SS49E Hall effect sensor 6x Neodymium magnet N35 5mmx2mm I connected the 3 hall effect sensors in parallel so that any increase in voltage from either of the 3 sensors would trigger a ball present. In the video i am using a arduino (Wemos D1) but in the final design it will be a simple resistor and transistor pair that will provide a signal much like any switch would. Twitter:   / maken_it_so   Instagram:   / maken_it_so   Snapchat: Maken it so thingiverse: https://www.thingiverse.com/mitchell_cj Github: https://github.com/boy1dr Hackaday: https://hackaday.io/Boy1dr
