How to program a capacitive level switch

In this video, you will learn how to use the inductive teach button to program an LI series capacitive level switch from ifm. The LI series from ifm uses capacitive technology as the sensing principle, which measures the permittivity of a liquid, or its ability to hold an electrical charge. This technology uses a constant voltage supply to charge a capacitor plate, which then creates an electrical field. It uses the ground as a reference when measuring the capacitance between the sensing element and its surroundings. The underlying sensing principles allow this sensor to detect the difference between presence of a particular media and foam or residue to ignore the latter. It can be used to measure mineral oil, coolant emulsion, glycol solutions, or water-based media. This level sensor performs best at: • Alarming at a high switch point for overflow protection • Leakage monitoring in an overflow basin • Alarming at a low level switch point to trigger a refill and/or to prevent a pump run dry situation Common industrial applications include replacing float switches, monitoring coolant level and temperature for cutting machines, and monitoring performance of Hydraulic Power Units (HPUs.) This one sensor can be used to prevent low levels of hydraulic fluid that would result in pump run dry situations or monitoring to prevent pump cavitation. Using IO-Link technology, you can receive point level and temperature values over a single wire, implement condition-based monitoring, simplify the design and commissioning process, receive real-time device status, and store setting preferences for automatic device replacement. This video applies to the following article numbers: LI5131, LI5132, LI5133, and LI5134. ⌚ Timestamps: chapters ================================================== Intro : 0:12 Online resources: 0:32 Demo setup: 1:27 Water-based media demo: 2:07 Inductive teach button empty teach: 2:32 Programming mode: 2:58 Teach mode for vegetable oil: 3:34 Additional Information: 3:47 ================================================== Missed our latest video? Catch up:    • How to install a capacitive level switch      • How to install an industrial point level s...      • How to program an industrial point level s...   ================================================== To find more information about the LI series capacitive level switch visit: Device Configuration for LI level sensors: https://www.ifm.com/us/en/us/learn-mo... LI Overview: https://www.ifm.com/us/en/us/learn-mo... LI Product Selector: https://www.ifm.com/us/en/us/learn-mo... ================================================== Subscribe to ifm USA to receive notifications when new videos are posted. Create a my ifm account to conveniently access all of your order & software download information: https://www.ifm.com/us/en/shared/my-i... Follow us on LinkedIn 👉   / ifm-efector   Follow us on X 👉   / ifm_usa   Follow us on Facebook 👉   / ifmefector   Visit our website 👉 https://www.ifm.com/us/en #howtoifm #levelswitch #levelsensor #IOLink
