TC420 with LDD-H

Dimming test for TC420 with LDD-H (acvariu.ro) Used: 1 x TC420 led controller 1 x Meanwell LDD-H 700 driver 1 x 24V~20A power supply with variable voltage 10 x Philips LUXEON Rebel ES Royal Blue 455nm leds As total voltage after LDD-H is 22V, had to bypass two leds to have enough voltage to reach 700mA through leds. Project started 26/03/2016, electric and engineering concept sorted 12/06/2016. Final product pending (next wage). Future purchase list: hole drilling bit for 120mm (aluminium holes) and guide drill bits, including sanding and smoothing bits 5x LDD-H (4x 700mA, 1x 500mA) 140mm Silverstone SST-FW141 PC Case Fan Special thanks to the colleagues on acvariu.ro forum, for their patience and tollerance of my ignorance, especially: liv1305 alexiumihai Akaiu darthradu Lucian rodoselada adiradu Pseudonimuss dan.pavelescu koala Shubi liv1305 A special mention for liv1305. Link: http://www.acvariu.ro/forum/posts/lis... Did I mention liv1305? Many thanks!
