LM-79 Compact Goniophotometer for Small Light Products Light Intensity Distribution Measurement

The LSG-1200A compact goniophotometer is used to measure the luminous intensity distribution curve, intensity data, beam angle and other photometric parameters for Chip LED, LED Module, LED Spotlight and all other light which spread angle is no more than 180 degree. Optional function: The LSG-1200A can work with a Digital Power Meter (LS2012 DC & AC Power Meter or LS2010 Harmonic Analyzer) and LSP-500VAR AC Power Source. Specification: • Meets the requirements of IEC, CIE and LM-79 standards • Measures beam angle automatically: 1/2 max intensity angle as well as 1/4 max intensity angle, 3/4 max intensity angle and 1/10 max intensity angle which meets the special requirements. • Measured data is matched with international standard form (IES) and can be applied for lighting design by other lighting design software such as DiaLux • LSG-1200A has a dark room that can measure the maximum size of luminaires: 180mm • Test range of light intensity: 0.1～30,000cd. Accuracy of the detector: Class A • The distance between the luminaire under test and the detector is 316mm or 1000mm • Angle interval: Horizontal angle: 1°/5°/10°/15°/22.5°/30°/45°/90°, Vertical angle: 0.5°/2°/1.5° • The LSG-1200A horizontal automatic rotating with an angle 0°~360° (C) and Vertical automatic rotating with an angle -90°~+90° (Gamma) • Test accuracy of angle: ±0.2° • LSG-1200A can be used together with a CCD Spectroradiometer to test spatial CCT Distribution and other Spectral color parameters. We call this system “Goniospectroradiometer (LSG-1200ACCD)”. The LSG-1200ACCD Goniospectroradiometer = LSG-1200A Goniophotometer System + LPCE-2 Integrating sphere Spectroradiometer System. Please click to download the LSG-1200ACCD Brochure ------------------------------------------------------------------------------------------------------------------------- Thanks for watching the video. Subscribe to the channel to get more and press the BELL icon to get updated about the new video. 💢 For More Information Please Visit ▶▶Website: https://www.lisungroup.com/products/g... Contact us： Tech Dep: Service@Lisungroup.com, Cell/WhatsApp: +8615317907381 Sales Dep: Sales@Lisungroup.com, Cell/WhatsApp: +8618917996096 Follow Our Social Media 🔶🔶 👉 Facebook:   / lisungroup   👉 Linkedin:   / lisun-group   👉 Twitter:   / lisungroup   COMPANY PROFILE ~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~ Lisun Instruments Limited was found by LISUN GROUP in 2003. LISUN quality system has been strictly certified by ISO9001:2015. As a CIE Membership, LISUN products are designed based on CIE, IEC and other international or national standards. All products passed CE certificate and authenticated by the third party lab. Our main products are Goniophotometer, Integrating Sphere, Spectroradiometer, Surge Generator, ESD Simulator, EMI Receiver, EMC Test Equipment, Electrical Safety Tester, Environmental Chamber, Temperature Chamber, Climate Chamber, Thermal Chamber, Salt Spray Test, Dust Test Chamber, Waterproof Test, RoHS Test (EDXRF), Glow Wire Test and Needle Flame Test. ~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
