Radiomaster 1W Ranger ExpressLRS Module 50mW dync FPV Testing in garden

The RadioMaster Ranger is the pinnacle of ExpressLRS module design. Built not only to look great but to last with its rugged CNC machined aluminum case that aids the high-efficiencty cooling system as a heat sink. The Ranger is up to any task and provides all the power and functionality you need. Featuring an OLED display, directional menu key and two assignable shortcut keys the Ranger can be adjusted on the fly and personalized to your needs. The Ranger includes a T Antenna for general use and a RadioMaster Moxon antenna for long-range directional applications. A micro module and nano module adapter are included to ensure the Ranger is compatible with most radios on the market today. A cable has also been included for use with Futaba radios that are CRSF capable. Except for the Ranger, we also provide the Ranger Micro and Ranger Nano for your choice. Features Rugged CNC Case High efficiency cooling system OLED Display Wifi and Bluetooth support Built in Accelerometer Packet rates up to F-1000Hz 5 Direction Nav key and customizable short cut buttons Up to 1 Watt Power output Specification Item: Ranger Module Regulatory Domain: ISM2400 MCU: ESP32(main), ESP8285(aux,as espbackpack) RF chip: SX1281IMLTRT Frequency Range: 2400 MHz to 2480 MHz Maximum packet rate: 500Hz/F1000Hz Minimum receiver refresh rate: 25Hz RF Output Power: 30dBm for FCC, 20dBm for CE (Adjustable by LUA) Module bay adapters: JR standard 5pin socket & Nano standard 8pin socket Futaba CRSF socket cable: Included OLED screen: 64x128px Wifi Support: Yes Bluetooth support: Yes 3 Axis Accelerometer: Yes (STK8BA58 MEMS Accelerometer) Built in RGB light strip XT30 Power supply voltage: DC 6V - 16V Weight: 138g (with Moxon antenna) / 135g (with T antenna) / 126g (without antenna) Dimension: 178*51*25mm (with Moxon antenna) / 95*51*25mm (without antenna) Package 1 * RANGER Module 1 * Futaba CRSF socket cable 1 * JR Adapter 1 * Nano Adapter 1 * T Antenna 1 * Moxon Antenna 1 * Hexagon socket screwdriver 3 * M2*5 Screws 1 * Assembly Manual Type: MOXON directional antenna Antenna polarization: vertical/horizontal polarization Frequency: 2.4GHz Type: T-type omnidirectional antenna Antenna polarization: vertical/horizontal polarization Frequency: 2.4GHz more：https://www.radiomasterrc.com/ Ranger 2.4GHz ELRS Module -https://www.radiomasterrc.com/product... Ranger Micro 2.4GHz ELRS Module https://www.radiomasterrc.com/product... Ranger Nano 2.4GHz ELRS Module -https://www.radiomasterrc.com/product... 2.4GHz T shape Antenna https://www.radiomasterrc.com/product... 2.4GHz Moxon Directional Antenna -https://www.radiomasterrc.com/product...
