Configuring Logging on NGM Power Supplies

This video goes step by step through how to configure both standard and “fast” logging on Rohde & Schwarz NGM series power supplies. Learn more about R&S NGM200 power supply series: http://rsna.us/6052cFzv0 Suggested viewing link: http://rsna.us/6053cFzvF Take the T&M Fundamentals courses and measure your knowledge: https://rohdeschwarz.talentlms.com/in... Timeline: 00:00 Introduction 00:15 Suggested viewing 00:44 Logging on R&S NGM power supplies 01:37 Configuring standard logging 02:05 Logging configuration 02:31 Setting log file save location 02:55 Setting logging interval 03:16 Setting logging mode 03:45 Count mode 04:10 Duration mode 04:28 Span mode 04:46 Starting and stopping logging 05:05 Configuring the user button for triggered logging 05:27 Logging active indicator 05:44 CSV settings 06:30 Example CSV log file 07:07 Configuring fast logging 07:31 Enabling FastLog 07:54 FastLog sample rate 08:16 FastLog logging location 08:37 Binary to CSV converter 09:08 FastLog CSV format (converted) 09:35 Summary
