Joule Motors High Voltage VESC 500Amps testing

The motors and controllers are available for sale. We are a company from the Netherlands, Joule Motors B.V. We have long background in motor design and now we also have our own controller in house design based on open source software from vesc done by Benjamin Vedder. We have done our own gate driver, to better integrate in to the controller, together with the back EMF and temperature readings. The motors are designed using computational electromagnetic (CEM) and finite element analysis (FEM). We are using solid state capacitors, that have high relativity and, custom capacitor bank. Controller details: Max Phase current: 500Amps DC-Bus voltage 680Vdc Cooling: Liquid Weight: 9kg Power: 250kW Communication: Can bus, Wi-Fi, Bluetooth, Android App, PPM throttle, 0-3,3v, Speed mode, Current mode, PWM mode, Rotor position: Sensorless, Encoder, Resolver. Motor: Continuous power 150kW Peak power: 280kW 0-7000 RPM Torque 400Nm Cooling: Liquid. Weight 49kg email for the enquiry: i.berca@joulemotors.eu website: masinaelectrica.com The controllers can be now ordered we are ramping up production. We are making now a lower power version up to 80kW @ 400v.
