How To: Removing a Fabricated Mower Deck with Simplicity® Quick Hitch™

You need to ensure you have sharp mower blades for you Simplicity® mower to get the best possible cut. Luckily, changing mower blades has never been easier with the Simplicity Quick Hitch™ Deck Removal System. Follow these easy steps to remove a fabricated mower deck with the Simplicity® Quick Hitch™ Removal System: 1. Turn the wheels completely to the left while the engine is still running if your model has power steering. 2. Apply the parking brake 3. Stop the engine and remove the key 4. Lower the attachment lift 5. Disconnect the lift assist springs and lift links on each side of the deck 6. Move the idler arm to release the belt tension 7. Remove the belt from the PTO pulley 8. Raise the attachment lift 9. Disconnect the electrical connector for the electric height of cut motor if your model has one 10. Pull back on the Quick Hitch™ removal level and lift the mower hitch off the bracket 11. Slide the mower out from under the tractor Learn more about Simplicity® tractor attachments at http://www.Simplicitymfg.com/us/en/at... Find more Simplicity® how-to articles for lawn mower & tractors at http://www.Simplicitymfg.com/us/en/su...
