EasyPLC Machine Simulator Analog Measurement Machine Using Studio 5000 with RSlinx OPC

Analog Pick & Place with a reject system. Another tutorial of using the EasyPLC software suite, this instance will be using Studio 5000 V31 with an RSlinx Classic OPC connection. You do not have to have one of the top names of programming software to work with EasyPLC because it has its own PLC programming software that comes with it. I just enjoy using the RSlinx OPC with Studio 5000 to program all of the machine examples that the software comes with. To get a discount on EasyPLC: email: Shane@OnlinePLCsupport.com 0:00 Introduction Pick & Place 0:30 Loading the OPC driver 1:08 Starting the machine 1:15 Explaining the PLC logic 1:45 State 1 measurement 2:00 Converting the measurement to pick movement 2:30 Explaining the Pick ladder logic 3:20 State 4 activate the pick action 3:35 State 5 Good or reject ladder logic 4:15 Reject part camera 4:40 State 8 indexing the place position out 5:00 Showing the analog values in EasyPLC 5:25 Releasing the reject parts 6:25 Showing the HMI Start/Stop function 7:30 Viewing the machine in trip mode 8:35 Sensor positions & side view Pick & Place 8:50 Pick Calculation in Ladder Logic 10:05 Releasing more rejects 11:20 Showing the RSLinx OPC connection 12:20 Viewing in full screen with analog values 13:45 Ladder Logic fullscreen 15:30 Recommended videos for you I hope it helped. Thank you for watching the video. Learn, Implement, Succeed Visit: https://www.allen-bradley-plc-trainin... Other social media: LinkedIn:   / shane-welcher-sr   Facebook:   / onlineplcsupport   #Studio5000 #MachineEmulator #EasyPLC
