Electrofusion | Semi Automatic 315mm

‪@marutisafex‬ Model: MSI 315 heavy duty electrofusion welding machine Electrofusion welding or called electric fusion welding is an convenient and reliable jointing method for PE, HDPE, PP pipes. The electrofusion welder, with various electrofusion pipe fittings, can finish the pipe connecting job efficiently. MSI-315, equipped with voltage protection cam operated rotary switch, industrial level electrical parts, either in-house or field piping jobs, can always provide steady welding performance. Date Sheet Model: MSI 315 Welding mode: Semi automatic and Manual Suitable material: PE PPR PB PVDF PP MPP(HDPE MDPE LDPE) Welding range: 20-315mm Power supply: 220V±20% 1PH Frequency: 50~60 Hz Power: 3.5 KW Ambient temperature: -15~45℃ Output Voltage : 0~50V adjustable Output Current : 0~55A adjustable Output accuracy: ≤ ±1.5% Control mode: Constant voltage/Constant current Display screen: LCD Time adjusting range: 1-999 seconds Duty rate: 80% Package data: 38X34X34cm(1/cartoon box-20 Kgs) Body Dimension: 31X22X22cm Product Description Electrofusion welding is widely used in PE and PP pipe jointing, with various kind of electrofusion fittings. With the tool of electrofusion welder, the connection job can be done efficiently. Our MSI 315 series electrofusion welder can provide flexible choice of welding, ranging from 20mm to 315mm. MARUTI SAFEX had been developing, manufacturing and distributing thermoplastic welding equipment since 2015. It's our pleasure to help you build reputation in the piping project. Product Application Gas and Water Utilities Civil Engineering and Storm Water management Mining Landfill gas extraction Geothermal – ground source heating District Heating and District Cooling Siphonic Rainwater Drainage Chemical Waste Oil and Petrochemical Product Characteristics Input Voltage Indicator. Scanner to Scan Fusion Fitting Barcode to Set Fusion Time. Last Set Data Remains Store Until You Will Set the New Data. Illuminated ON / OFF Switch. Illuminated START / STOP Push Button. Fusion Process Indicator LED. Selector Switch to Set Input Voltage as Per Supply Voltage for Constant Output Fusion Voltage. Count Down Timer Along with Fusion Voltage & Ampere Meter. Audio Visual Signal for Fusion Process Completed. Audio Visual Signal for Cooling Process Completed. Stop Button to Stop Fusion & Cooling at Any Stage. Face Lift Design with Big Display for Easy Operation. Easy Lifting Handle & Cable Clamp On Top. ‪@marutisafex‬ ​
