Fly Over Neoprene Elastomeric Bridge Bearing Pad

There are several different and similar types of Elastomeric Bridge Bearings that include Neoprene bearing pads. Elastomeric Bridge Bearing | Sandhya Enterprises | Elastomeric bearing pads compress on vertical load and accommodate horizontal rotation and provide lateral shear movement. Elastomeric bearing pads are the most economical solution used in construction of large span bridges and buildings. Preventing collapse is not the only function of an elastomeric bearing pad. The pads extend the life of bridges by reducing wear and tear on bridge materials. Manufacturer of Bridge Bearing Pads - Elastomeric Bridge Bearing Pads, Rubber Bridge Bearing Pads, Neoprene Pad and Elastomeric Rubber Bearings. Elastomeric Bridge Bearing- The company has segregated its infrastructure into several units. FLY OVER ELASTOMERIC BRIDGE BEARING : - An elastomeric bridge bearing is a commonly used modern bridge bearing. There are several different similar types of bridge bearings that include neoprene bearing pads, neoprene bridge bearings, laminated elastomeric bearings and seismic isolators, which are all generally referred to as bridge bearing pads in the construction industry. They are designed and manufactured based on standards and specifications of such organizations as British Standard, AASHTO, and European Norms En 1337. [1] Internal structure consists of a sandwich of mild steel shims and rubber molded as one unit. Elastomeric bearing pads compress on vertical load and accommodate horizontal rotation and provide lateral shear movement. Elastomeric bearing pads are the most economical solution used in construction of large span bridges and buildings. Elastomeric Bridge Bearing: - The company has segregated its infrastructure into several units and one of them is packaging unit wherein we meticulously pack our Elastomeric Bridge Bearing for ensuring safe and secure deliveries. For the safe storage of the entire lot, we have installed our own facility that is laced with all the modern amenities for complete quality satisfaction. Features : - Strong design Simple installation High quality. Use : Allows movement in any direction. Applications : - Bridges Buildings Auditoriums Stadiums etc. Elastomeric Bridge Bearing Technical Details 1 Hardness IRHD IS: 3400 (Part II) Cl.5.1.2.2 4.0mm (min ) thickness of Test specimen 2 Tensile Strength MPa IS:3400 ( Part I) Thick- 2.0 +.0.20mm 3 Elongation at Break % Table 1 Type -1 Width 6.0 + 0.40mm Bench Mark-25..0mm (max) 4 Adhesion Strength (Metal to Rubber KN/M IS:3400 ( Part XIV) Cl.3.3 Length -125mm Width-25mm Width-25mm 1 g (min) 5 Ash Content % IS:3400 (Part XXII) 1 g (min) 6 Polymer Identification Chemically Cl. A-8.3.1 IS 7 Percentage of Polymers % IS 0.5 g (min) 8 Compression Set % IS: 3400 (Part X) Cl. 5.1 Thick -12.5 + 0.50mm 9 Elastic Modulus MPa IRC 83 (Part II) Dia-29 + 0.50mm 2 Nos from Finish 10 Shear Modulus MPa 1987, UIC 772 -2R Product 11 Ultimate Compression Strength MPa and MORTH One Specimen size of 100x200mm (Cutting Piece from Finish product.) 12 Stripping Strength (Adhesion Strength) MPa Two Specimen size of 100x 100mm (Cutting from Finish Product) 13 5MPa and 15 MPa Deflection Test MPa IRC 83 (Part II) 1987, and MORTH 100% on finish Product. Q&A on Comments
