Stratasys Academy | F770 3D Printer: Z Motor Removal and Installation

Learn how to safely remove and install the Z motor on the F770 printer. This step-by-step guide ensures proper handling and reassembly for both the left and right Z motors. 🛠️ Overview: This video demonstrates the removal and installation process for the Z motor on an F770 printer. Follow the instructions to safely disconnect cables, remove the Z motor, and reinstall it with the correct torque specifications. 🔑 Key Steps Covered: • Z Motor Removal: Power off the printer and open the electronics bay and side access doors. Disconnect the Z motor cables and release cable ties. Loosen the Z motor tension bracket screws and remove the Z drive belt. Detach the Z motor by unscrewing the mounting screws. • Z Motor Installation: Position the Z motor within the bracket and secure it with screws torqued to 21 in-lbs. Reinstall the Z drive belt and reconnect the cables to the I/O board set. Route and secure cables using reusable cable ties and close the access doors. Thanks for watching! 👍 Like and Subscribe for more helpful tutorials. 🌐 Learn more: For more information on the F770 printer, visit Stratasys Academy online: https://support.stratasys.com/en/Welc... #F770 #ZMotorReplacement #PrinterMaintenance #StratasysAcademy
