Les boutons dans tous leurs états avec ESPHome

Tout (ou presque) ce que vous devez savoir sur les boutons avec ESPHome !!! Code Yaml : web_server: #ESP32 --- Bouton #GND --- GND #3V3 --- VCC #D13 --- OUT web_server: binary_sensor: boot button platform: gpio pin: number: GPIO0 mode: INPUT_PULLUP inverted: True name: "boot button" id: "boot_button" Red button platform: gpio pin: number: GPIO13 #mode: INPUT_PULLUP inverted: False name: "red button" id: "red_button" on_press: then: logger.log: "on_press" on_release: then: logger.log: "on_release" on_state: then: logger.log: "on_state" on_click: min_length: 50ms max_length: 350ms then: logger.log: "short click" min_length: 351ms max_length: 2000ms then: logger.log: "long click" EndStop button - platform: gpio pin: number: GPIO15 mode: INPUT_PULLUP inverted: True name: "End Stop button" id: "endstop_button" PULLUP button platform: gpio pin: number: GPIO15 mode: INPUT_PULLUP inverted: True name: "PULLUP button" id: "pullup_button" filters: delayed_on: 10ms 0:00 Présentation 0:55 Bouton flash 2:06 Module bouton 3:10 Endstop 3:45 Bouton sans resistance Pullup 5:07 Filter delayed_on 5:46 Switch 6:15 Les triggers on_press / on_state 6:58 Short click / Long click 7:30 Composants boutons
