CimatronCAM Tutorial 15: 2 5 Axis slotting-Open & closed contour machining

Cimatron's 2D machining capabilities are focused on generating toolpaths for milling or cutting operations that involve two-dimensional shapes and features. These features include slots, pockets, profiles, contours, and simple geometries. In 2D machining, the software allows users to define the geometry of the part they want to machine and specify the tools and machining parameters. Based on this input, Cimatron generates toolpaths that guide the cutting tool along the X and Y axes to remove material from the workpiece. Some common operations in Cimatron's 2D machining module include: Pocketing: Removing material from within closed contours or regions to create pockets or recesses in the part. Profiling: Cutting along the outline of a part or feature to achieve the desired shape. Contouring: Following the contour of a part or feature with the cutting tool to achieve precise dimensional accuracy. Drilling: Creating holes or openings in the workpiece using drilling tools. Cimatron provides users with various options and parameters to customize the toolpaths generated during 2D machining. This includes specifying cutting speeds, feed rates, stepovers, toolpath strategies, and other parameters to optimize machining efficiency and achieve desired surface finish. Overall, Cimatron's 2D machining capabilities are suitable for a wide range of industries and applications, including mold making, tool and die manufacturing, and general machining tasks where parts have relatively simple geometries. #cadcam #cncmachine #Zecha #takumi #cimatron #vmc #sandvik #RegoFix #tooling #Cornering #roughing #diet #machining #cadcam #toolroom #core #cavity #hurco #cuttingtools #3Axis #gcode #mcode #rpm #feed #cutting
