Based on ESP32-S3 driver 7-inch 800 * 480 color screen - ZX7D00CE01S or WT32S3-07S

Hi everyone! Today, I will take a look at our color screen products, which have been widely applied in many projects; Because when we design and produce, we consider that they not only serve as development boards, but also can appear in the products you design;In the video, I introduced two ways to create UI, the first being to develop UI on the 8ms platform; The second type is that there are many pre made UI on the 8ms platform, which can be directly cloned into the project. Afterwards, the UI display content can be modified or added. Once satisfied, download the source code and cooperate with the SDK provided by smartpanel for secondary development; Of course, you can also choose the third method, directly applying LVGL to compile the UI for engineering development!So, among many products, we still chose a 7-inch color screen product today. Why? First of all, I think the ESP32-S3 driver with a 7-inch 800 * 480 resolution and touch function color screen is a miracle. Here is a note of the product name ZX7D00CE01S or WT32S3-07S. When designing this product, in order to have enough IO ports, we added an AW9523B expansion chip, which is attached to the IIC bus of the board, In this way, I can add 7 more high-speed IO and 7 more low-speed IO. At the same time, I have also built an audio sub board and an RS485 sub board for expanding IO, which is convenient for applications in more scenarios;Now let's take a look at the DEMO of the coffee machine we made today
