How This Compact Swing-Lever Core Pull Solves Tight-Space Mold Challenges

This video showcases a compact swing-lever (rocker arm) core-pull mechanism designed for injection molds with very limited space. When traditional sliders or hydraulic core pulls cannot be installed due to space constraints, the swing-lever mechanism provides an efficient solution. It converts linear motion into angular core extraction, making it ideal for slim mold layouts and small precision components. 🔧 Key advantages: • Ultra-compact structure for tight mold spaces • Converts linear movement into angular side-core action • Simple mechanical design with stable, reliable motion • Suitable for high-precision small parts and limited mold layouts At Moldevo, we design advanced molding mechanisms using NX and Moldflow to ensure smooth motion, manufacturability, and reduced trial iterations. 👉 Want us to review your design? Email your 3D model to: moldevo.design [at] gmail [dot] com Or DM us on LinkedIn. #InjectionMolding #InjectionMoldDesign #MoldDesign #CorePull #DFM #MoldEngineering #Moldevo
