How to Install 10M Honeycomb Glass Dome

A step-by-step guide to installing the RAXDOME 10-meter honeycomb glass dome. Step 1 — Assemble the Frame Assemble the aluminum modules according to the drawings, pre-connecting them into quadrilateral, pentagon, and hexagon shapes. Identify the door position and start assembling from both sides. Secure all joints with bolts and check tightness after each layer. Use a lift or scaffolding for higher sections, stacking layer by layer until the top pentagon is fixed — completing the main structure. Step 2 — Install RAXDOME Double-Layer Insulation Next, Install the interior aluminum insulation panels to protect privacy, block UV rays, and improve heat and sound insulation. Seal the edges with structural adhesive for waterproofing. Then apply 20mm aluminum foil insulation layer — (foil on one side, adhesive on the other). Peel off the adhesive backing, press the insulation onto the panels, and smooth it flat for a tight bond and nice thermal performance. Step 3 — Install Exterior Tempered Glass The dome uses 5 + 9A + 5 mm insulated tempered glass. Before installation, apply masking tape around the glass edges. Place each glass into the frame and press it gently to seat it. Fill seams with structural adhesive and remove excess for a clean finish. Install from the top down for full waterproofing. For the bottom layer, support the glass with wooden blocks for 12 hours while the adhesive cures, then remove the supports once fully set. Step 4 — Install Windows & Ventilation Install the hexagonal glass windows and solar exhaust fan using pre-drilled holes. For large domes, optional electric windows can be added for better airflow. The hexagonal window design allows for maximum ventilation, optimizing airflow within the dome. Step 5 — Final Inspection & Testing Check the entire structure — frame stability, glass sealing, and ventilation performance. Once all tests are complete, your RAXDOME honeycomb glass dome is ready. Web: https://www.raxtent.com/products/raxd... Whatsapp/ Cel: +86 139 2910 9629 / +86 138 2211 5092 Wechat: +86 139 2910 9629 Email:raxtent@raxtent.com Official website: www.raxtent.com Facebook: @raxtent TIKTOK: @raxtent
