4 channel 50A charge discharge machine // best machine for lithium battery making& testing

machine price 54999/- Location :- katni, Madhya Pradesh WhatsApp 62669 66461 https://wa.link/fa83o5 website https://vipultech.in/shop/ please watch latest video for new Price वेबसाइट https://vipultech.in/shop/ कृपया नई कीमत के लिए नवीनतम वीडियो देखें 4 Channel 5V 50A Charge Discharge Capacity Tester https://vippotech.in/product/9-99v-20... Battery Charge/Discharge Machine DK 10A/20A https://vippotech.in/product/9-99v-20... 9-99V 20A Universal Charger DK https://vippotech.in/product/9-99v-20... Specification Name: 4-channel 50A Battery Capacity Tester Voltage: 220V / 110V (optional) Power: 1000W Model: YPSDZ-0550-4 Menu: Chinese/English Channels: 4 channels isolated and independent work Charging range: 1-5V adjustable, 0.5-50A adjustable, constant current - constant voltage Discharge range: 1-5V adjustable, 0.5-50A adjustable, constant current discharge (no spike pulse) Work step: charge/discharge/cycle 1-5 times Net weight: 6.4kg Size: 620*105*230mm Package Included: Battery Capacity Tester*1pc Power Adapter*1pc Manual*1pc Clamp*4pcs (Gift) Extended functions: 4 channels can work in parallel after the same parameter setting, realizing 200A charging and discharging. Any 4 cells in a series battery pack can be tested without removing the connecting tabs. Auxiliary function: equalization mode (discharge equalization) Protection function: battery over-voltage / battery reverse / battery disconnection / high temperature alarm and protection Accuracy: Voltage ±0.2% Current ±0.2% Allows calibration by authorized users Heat dissipation: temperature-controlled fan 40 ℃ open, 83 ℃ protection (please check and maintain the fan operation regularly) Working environment: 0-40 ℃ ventilation, do not let the heat accumulated around the radiator, if necessary, can be used to increase the air flow of electric fans blowing against the radiator Applications: It can be used for single cell dividing or battery pack rapid equalization; Suitable for lithium ternary, lithium iron phosphate, manganese/cobalt/lithium titanate polymer batteries Please note: 1. This product can not test more than 5V battery; 2. Requires the clamp and battery lug contact area is large enough, otherwise there will be a failure, and the clamp can not be repaired 3. During the upgrade process, the appearance will change slightly, default to send the latest version, thank you~ High Precision 4 Channel 5V 50A Charge Discharge Detector Battery Pack Voltage Balance Lithium Battery Capacity Tester - Battery Analyzer. 4 channels are isolated from each other and work independently Charging mode CC-CV Discharge mode CC (no spikes and pulses) Working steps charge/discharge/cycle 1-5 times Protection functions Battery overvoltage/battery reverse polarity/battery disconnected/fan not running Professional calibration accuracy V±0.1%, A±0.3% (allow authorized users to calibrate) Cooling 40 ℃ fan off (regular maintenance fan) The working environment is 0-40°C, the air is ventilated, and the heat is not allowed to accumulate around the machine High precision and more professional, this is a capacity tester with voltage equalizer function Quick test capacity for 1-5V 2-999Ah batteries It is also possible to charge or discharge some cells in the battery pack individually according to your requirements without disassembling the battery pack Suitable for flexible packaging batteries, the contact area between the clip and the battery sheet must be large enough, otherwise the clip is easy to burn out The clip has good compatibility, and the contact area between the clip and the battery label must be large enough, otherwise it is easy to burn the clip #testingmachine #lithiumbattery #lithium #lifepo4
