Electric Scooter Testing Metre Devices Detailed Review In Hindi | Controller And Motor Testing AtoZ скачать в хорошем качестве

Electric Scooter Testing Metre Devices Detailed Review In Hindi | Controller And Motor Testing AtoZ

Please watch: "Lithium battery BMS reset and battery working condition |lithium ion battery BMS reset |BMS reset |"    • Lithium battery BMS reset and battery work...   -~- Hi I AM [ SR SACHIN SR ]    / @srsachinsr   ======================================================== Facebook ======   / srsachinsr.prajapati   Instagram=======   / srsachinsrprajapati   =============================================================|| All Types Of Bike Faults And Other New Bikes Are Available On Our Channel || =============================================================| Electric Scooter 24-96V Motor Controller Tester Brushless Hall Detector *100% brand new and high quality *Made of high quality materials, durable and practical *Material: Nylon Hard Plastic Shell |Notice: Only when using Hall detection and shifter detection, you need to turn on the power. When the signal light is not bright enough, please replace the battery. 1. Motor coil detection: connect the three alligator clips on the motor coil end of the tester to the three thick cables of the motor and rotate the motor. The three signal lights flash in turn, which is normal. If the light is not bright, then the winding has malfunction. 2. Motor Hall detection: connect the motor Hall line on the tester to the Hall line of the motor, and slowly rotate the motor. The three signal lights should have on and off changes. If there is no change, the corresponding Hall or line has malfunction. 3. When the 60° signal light is illuminated, it indicates that the motor is 60°, otherwise it is 120°. 4. Motor phase sequence detection (1) Hall phase sequence (a) 60 ° motor (b) 120 ° motor (2) Winding phase sequence Through this step, the alignment of the windings of the controller and the motor with Hall's color cables 5. Shifter Detection: Connect the three alligator clips on the tester shifter detection end to the shifter and turn the shifter. The shifter signal light should have on and off changes, otherwise there is malfunction. 6. Controller Detection: This instrument is suitable for the detection of 24V to 60V brushless controller. ○1 Connect the controller Hall input terminal to the tester controller Hall line terminal. ○2 Connect the controller main line output terminal to the tester controller main line terminal. Turn on the power of the controller, the 5V indicator on the tester should be lit. If it is not lit, it indicates that the 5V output of the controller has malfunction. Turn the shifter, the six lights of the controller on the tester should be lit in order (two signal lights are a group). If it is not lit or two groups are flashing at the same time, the controller has malfunction. *Multi-function fast and accurate detection of brushless motor Hall / controller / shifter/ brake level detector, a good helper to repair the vehicle *Brushless motor, controller, shifter, brake lever, Hall detector, and has nothing to do with electric scooter 36V, 48V, 60V, 64V, 72V power supply *Electric scooter multi-function maintenance tester for 24V, 36V, 48V, 60V brushless controller, brushless motor coil, brushless motor Hall, shifter detection and brushless motor angle distinction. *Repair tester is only to help detect the diagnosis fault, the detection controller is not 100% completely detected, only the phase line and Hall line interface of the controller are detected. If the signal component and the power switch component are damaged inside the controller, it will also cause the controller not to work properly, and the tester can not judge *Note: The tester cannot work effectively for Hallless or dual mode and sine wave controllers! The controller is recommended to be installed on the electric scooter to connect the motor for testing: accurate and effective! *Turn on the power switch, the power indicator and the shifter detection lighting together shows it is normal (caused by the high sensitivity of the shifter detection), and does not affect the use. *Overspeed controller / discharge instrument / 5-way 6-way tester *Applicable to 9V battery, 9V battery is not included in the porduct Package Contents: 1*Tester 1*Instruction manual Note: 1. The real color of the item may be slightly different from the pictures shown on website caused by many factors such as brightness of your monitor and light brightness. 2. Please allow slight manual measurement deviation for the data. ----------------------------------------------------------------------------------------------------------- #srsachin#ebike#allbike#lucknow
