Structural Steel Drilling with Plasma and Oxy Fuel Cutting

https://www.ficepcorp.com/Drilling.cfm The CNC beam drilling line with robotic thermal processing uses unique steel fabrication technology to achieve industry-leading productivity. This complete integration of structural steel drilling, scribing and milling with thermal cutting delivers capabilities not available on typical CNC drilling lines for steel. This automatic steel fabrication line includes the steel fabrication technology of thermal cutting that FICEP innovated in the late 80’s to employ robotics to thermally generate copes, mechanical opening, rat holes, weld prep, cut off and more. The ability of the robot to use both plasma and oxy-fuel thermal cutting technologies in conjunction with an automatic torch changer greatly expands the productivity and versatility that can be achieved. Web cuts, like narrow copes, that require cutting next to the flange can be achieved with the oxy-fuel torch where the plasma torch is too large to achieve these cuts. The oxy-fuel torch also expands the capabilities of the system when thicker material must be processed. The systems drilling capability starts with an innovative spindle design that enables up to three surfaces to be processed with the same spindle. The “Direct Drive” spindle features a 17 KW (23 HP) motor for speeds up to 5,000 RPM. This unique “Direct Drive” spindle design delivers 100% of the motors power to the tool. Each spindle and the underside-scribing tool can be furnished with a sub-axis option to permit simultaneous functions even when the required hole or scribe locations for example are not in line. FICEP invented and patented the automatic importation of the locations of the intersecting members from the 3-D model. This innovative patents eliminates any manual programming to establish not just holes but all the required layout locations, orientation and welding symbols.
