Vertical Lathes carousel Soustruh svislý dvoustojanový SK 16 CNC ID:10837

Item: Vertical Lathes (carousel) Catalogue No.: 10837 WWW: https://strojesvoboda.cz/e10837 Model, parameters: SK 16 CNC Producer: TOS Production/refurbished: ???/2008 Description: max. diameter of turning left smykadlovým slide 1700 mm max. distance between the clamping plate and knife holder slide left ram 1250 mm max. ram extension Left slide in 660 mm Max. protrusion of the turret slide 550 mm Z Revolving slide cross travel X 1020 mm cross travel slide left ram U 980 mm Clamping plate diameter 1620 mm max. workpiece weight of about 5000 kg max. section of the body knife 40x40 mm Power of main engine control and 30 kW / A 52.3 nominal speed main engine 1475 rev / min. servomotors lateral displacement X, U 22 Nm -3000 rev / min. Servomotors strips Z, V 22 Nm -3000 rpm / min. SERVOSTAR 614 servo inverters hydroaggregate motor power of 2.2 kW (1450 rev / min.) SINUMERIK 840 Di Number of NC axes 5 position measuring axes X, U, Z, V Transducer rotating table hydraulic power unit: Nominal tank capacity of 30 dm3 Supplied quantity 10 dm3 / min infinitely variable speed in 4 rows for running left and right: Series I. 1-12,5 rev / min. II. range 5 to 27 rev / min. III. range from 10 to 60 rev / min. IV. range from 15 to 122 rev / min. rychlopusuv: Programmed in all slides 5000 mm / min. In manual mode 4500 mm / min. Machine floor space (WxD) 4550x2670 mm machine height above ground 4630 mm weight machines, including electric. cabinets and units of about 18500 kg max. diameter of turning left smykadlovým slide 1700 mm max. distance between the clamping plate and knife holder slide left ram 1250 mm max. ram extension Left slide in 660 mm Max. protrusion of the turret slide 550 mm Z Revolving slide cross travel X 1020 mm cross travel slide left ram U 980 mm Clamping plate diameter 1620 mm max. workpiece weight of about 5000 kg max. section of the body knife 40x40 mm Power of main engine control and 30 kW / A 52.3 nominal speed main engine 1475 rev / min. servomotors lateral displacement X, U 22 Nm -3000 rev / min. Servomotors strips Z, V 22 Nm -3000 rpm / min. SERVOSTAR 614 servo inverters hydroaggregate motor power of 2.2 kW (1450 rev / min.) SINUMERIK 840 Di Number of NC axes 5 position measuring axes X, U, Z, V Transducer rotating table hydraulic power unit: Nominal tank capacity of 30 dm3 Supplied quantity 10 dm3 / min infinitely variable speed in 4 rows for running left and right: Series I. 1-12,5 rev / min. II. range 5 to 27 rev / min. III. range from 10 to 60 rev / min. IV. range from 15 to 122 rev / min. rychlopusuv: Programmed in all slides 5000 mm / min. In manual mode 4500 mm / min. Machine floor space (WxD) 4550x2670 mm machine height above ground 4630 mm weight machines, including electric. cabinets and units of about 18500 kg GO 2008
