Introducing TheWeeO3

The Wee O3 is an Arduino Nano based emulation of a Korg Mini Pops drum machine. The O3 follows Jan Ostman's O2 from 2016 with additional features and optimizations for the Korg SQ-1 sequencer. Code and schematics are available on GitHub: https://github.com/mark-orion/The-Wee-O3 New Features: Analog pitch control via potentiometer or CV input. Changing the pitch will change the tempo as well because pitch control is achieved by changing the interrupt timing. Combined CV / potentiometer input for selecting a sample (rising edge) and triggering it (falling edge). Compatible with the littleBits OUT of the Korg SQ-1 sequencer. Manual S Trigger input for triggering the selected sample. Bi directional clocking: Turning tempo all the way down disables internal clock and switches system to clock input. CV input for tempo control. CV input for drum pattern selection. Double functionality for A0-A3: Sequence counter when running, pattern number when stopped. LEDs or a display connected to these pins make pattern selection easier.
