Import an airfoil | EP03 | 2D Airfoil Masterclass

In the third episode of our masterclass, we explore how to import airfoil sections from various sources and seamlessly integrate them into our NURBS parametric model. ▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬ 🔍 WHAT WE COVER IN THIS EPISODE: Generate & Fit NACA Sections: Learn to generate NACA 4-digit, 5-digit, and 6-series profiles directly within the tool. External Databases: How to import and fit sections from popular online databases http://airfoiltools.com/ https://m-selig.ae.illinois.edu/ads/c... Import files: .arf: Native NURBS format used in various airfoil tools. .dat / .txt / .csv: Import point clouds (2D or 3D). We'll show you how to handle unsorted data. .igs / .iges: Import 2D sections or 3D samples. Ideal for extracting geometry from external CAD software. ▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬ 💻 TOOLS & SOFTWARE: Everything in this tutorial is performed using the TakeOff Technologies 2D Section Design Suite. 👉 https://app.takeoff-technologies.com ▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬ 🔍 VIDEO CHAPTERS: 0:00 Introduction 0:40 NACA 2:50 http://airfoiltools.com/ 3:30 https://m-selig.ae.illinois.edu/ads/c... 4:30 arf files 5:30 dat/txt/csv point files 6:10 igs files 11:50 all imported sections and conclusions ▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬ 📈 ABOUT 2D Airfoil Masterclass This series is a deep dive into the "science of the section." We are stripping back the complexity of 3D design to focus on the fundamental building blocks of flight and lift. Whether you are designing for the America's Cup, IMOCAs, or high-performance UAVs, this masterclass provides the technical foundation to optimize your foils from the very first pixel. By the end of this series, you will be able to: Master the physics behind 2D section performance. Optimize geometries for any specific operational condition. Generate high-fidelity 2D CAD models ready for production. Subscribe and hit the bell 🔔 to master the art of foil design. #AirfoilDesign #Hydrodynamics #Aerodynamics #Engineering #FluidDynamics #CFD #Optimization #TakeOffTechnologies #NavalArchitecture #2DSection
