Analog DRO: Installing a Trav-a-Dial on a Harrison L6 Mk1 lathe

Does your lathe lack a scale on the x axis? Are you frustrated by having to reposition a dial indicator several times to measure large distances? Worry no more, for trav-a-dial is here. It functions via a disk pressed against the side of the lathe, spinning the dial through FANCY GEARS Also it's a PITA to calibrate. Rough heuristics used during calibration: Repeatability: 1. Move saddle right to a consistent location 2. Move saddle left to a consistent location 3. Return saddle to the right 4. Record the position of the dial 4. If the needle is to the right of 0 tilt it left 5. If the needle is to the left of 0 tilt it right 6. Repeat, many times Absolute: 1. Zero an indicator on the saddle 2. Move the saddle exactly an inch (1.000") 3. If the needle is to the left of 0 tilt it forward 4. If the needle is to the right of 0 tilt it back Note: my lefts and rights might be backwards. Best of luck to any other poor sods installing one of these, be diligent and patient with your notes. Timecodes and installation steps: 0:00 - 0 Intro 0:18 - c. Context 1. Fabricate Bracket 1:00 - a. Determine Location 1:13 - b. Cut Stock 1:20 - c. Design Bracket 1:30 - d. Weld Bracket 2:18 - e. Layout Mount 2. Mount 4:09 - a. Transfer holes 4:25 - b. Drill and tap 5:35 - c. Attach this 3. Calibrate 6:13 - a. Rough Horizontal 6:42 - b. Explain Adjustment 7:33 - c. Fine Horizontal 9:00 - d. Tune Nod 10:00 - e. Adjust and repeat Footage: By me Sounds: Metal snapping - https://freesound.org/people/Ashley12... - CC0 - Ashley12275 You found the - https://freesound.org/people/javapimp... - CC BY 3.0 - javapimp Fail Sound Effect - https://freesound.org/people/florianr... - CC0 - florianreichelt Music: "Floaters" by Jimmy Fontanez "Marble Machine" by Wintergatan This track can be downloaded for free at www.wintergatan.net Free License to use this track in your video can be downloaded at www.wintergatan.net analog digital read out lol
