How to Rebuild the Harken Cam Cleat || Tech Team Express

A simple, step-by-step how-to video with no words. This Tech Team Express Video shows you how to rebuild the Harken 150 Cam-Matic Cam Cleat using part #150KIT. DISSASSEMBLY 1. Remove cam from deck. 2. Take off red baseplate. Carefully work one end of baseplate up, then other. 3. Remove torsion springs. 4. Carefully put small bolt through fastener hole to remove red cam caps. 5. Lift cam off base, remove balls. 6. Lift off red plastic washer. 7. Remove remaining balls. CLEANING / REPAIR 1. Replace plastic parts, balls and springs as needed. 2. Wash parts using soap and hot water. REASSEMBLY Tip: When replacing balls, you can use shaving cream or liquid detergent to keep balls in place on race. 1. Put 11 balls in lower race. 2. Put on red plastic washer, lip up. 3. Put 11 balls in next race. 4. Replace aluminum pawl. Make sure it seats on balls. 5. Fill cam top with 11 balls. 6. Push in red plastic cam cap. 7. Repeat steps 1-6 on other cam. 8. Turn cam over. Replace torsion springs. Hook each end of spring around posts. Tip: Use two springs on each side to stiffen cam action or to act as a backup if first spring breaks. 9. Push on red plastic baseplate. Plate is not symmetrical. Make sure to orient it correctly. 10. Flush shaving cream/soap away using fresh water. 11. Install cam on boat. Do not over-tighten mounting screws; pawls will bind. Rebuild kit is available at your local dealer or online here: https://bit.ly/CamCleatRebuildKit
