Extraction & Processing Eqpt Auction Lot 509 - 2019 FEYECON D&I SUPERCRITICAL CO2 EXTRACTION UNIT

2019 FEYECON D&I SUPERCRITICAL CO2 EXTRACTION UNIT - LIKE NEW CONDITION W/ SIEMENS CONTROLS #1 SN:5130-A EXTRACTOR SPECIFICATIONS: 48.3 HORSEPOWER 480V 3PH 60HZ 250 FLA CO2 CONNECTION SIZE: 0.5" CO2 FLOW RATE: 80 LBS/HR CHILLED WATER CONNECTION SIZE: 1.5" CHILLED WATER CONNECTION FLOWRATE: 15 GPM EQUIPPED WITH: STAINLESS STEEL JACKETED EXTRACTION VESSELS SPECS: X2 TOTAL SPECS ARE WRITTEN FOR INDIVIDUAL TANKS 35 GALLONS 13" DIAMETER 70" TOTAL HEIGHT, 60" BETWEEN STRAIGHT SIDES TANK BODY: MAWP: 350/-5 BARG @ 100C (5,000 PSIG/ -72PSI @ 212F) MDMT: 0C @ 350/-5 BARG (-32F @ 5,000 PSIG/ -72 PSIG) TANK JACKET: MAWP: 5 BARG @ 100C (72PSI @ 212F) MDMT: 0C @ 5 BARG (-32F @ 72PSI) PUMP SPECIFICATIONS: 2019 SPECK-KOLBENPUMPENFABRIK P52/51-300CZ PUMP PUMP SPECIFICALLY DESIGNED FOR OPERATION WITH CO2 FLOW RATE (MAX): 13.5 GPM OPERATING PRESSURE (MAX): 4,350 PSI POWER REQUIREMENT: 40.2 HP PUMP SPEED: 1000 RPM WEIGHT (APPROX): 183 LBS INLET TEMPERATURE: DOWN TO -40F (SPECIAL CO2 RATING) MOTOR SPECIFICATIONS: AC-MOTOREN GMBH ACM 225M-6/HE 460V 60HZ 36KW (48HP) 1170 RPM DELTA T SYSTEMS KK-471S TEMPERATURE CONTROL UNIT 460V 3PH 60HZ 115A 90 KW 3 HORSEPOWER DELTA T SYSTEMS KI451S TEMPERATURE CONTROL UNIT 460V 3PH 60HZ 80A 60KW 1.5 HORSEPOWER OVERALL SKID DIMENSIONS: 19'L X 8'W X 8'T THIS LOT ALSO INCLUDES BLACK SUPPORT BEAM FOR PIPING BEHIND EXTRACTOR
