NEW Pressure Regulator - Exchange of Air Filter with Pressure Adjustment - Schaller Automation

This clip demonstrates the procedure of how to exchange the air filter in the upgraded pressure regulator unit (standard with Visatron VN2020) and how to re-adjust the air pressure. Air Filter (P/N 366717) in Pressure Regulator unit replacement procedure: 1. Close the air supply. 2. Remove the filter cage as shown. 3. Unscrew the lock screw below the filter. 4. Remove the used air filter and replace with a new one. 5. Fix back the lock screw below the filter as shown. 6. Fix back the filter cage (ensure the blue slider to click in position) Adjust the Pressure: 7. Connect air pipe adapter and pressure gauge (P/N 151800) to control/inspection cover. 8. Lift the adjustment wheel. 9. Turn the knob to set the pressure to approx. 60 mmWC (see manual p. 30/50) 10. Press down the knob to fix it in position 11. Confirm that the OMD shows the “Ready”-Mode 12. Replace the filter every 4000hrs/6 months. Pressure adjustment every 2000 hours. Spare Parts or complete Spare Part Kits can be ordered from Schaller Automation Singapore Pte Ltd which provides the vessel with all the necessary parts required for regular maintenance. Schaller Automation is the market leader for the most reliable and advanced Oil Mist Detection products available. Contact Schaller Singapore at info@schallersingapore.com for more details and visit us on www.schaller.sg Be aware of non-authentic grey market offers and advertisements, don’t fall for it! Stay safe with genuine products and parts from your trusted maker. All Schaller products carry serial numbers! Watch more clips for more Maintenance support on our YouTube channel and call us in case of questions. #SchallerAutomation
