Rose Forgrove,intermittent motion, double twist, wrapping machine

To view additional machinery on our website click here: http://www.fraingroup.com. Rose Forgrove Model 22B, automatic, intermittent motion, double twist, wrapping machine rated up to 230 product wraps per minute - depending on materials, application and machine configuration. Size range: 16mm to 60mm in Length: 32mm to 86mm in Width; 9mm to 22mm in Height and is capable of handling pralines or bar end twist and end folds of most sizes and shapes. Equipped with 27" x 22" x 7" product accumulation table with 17" OD, 26 pocket hand load product disc, 9" OD foil film rollers with cut-off, form, fold and twist sections and 32" long x 4" wide product discharge chute. Control panel has start, reset and stop push button controls. Mounted on epoxy coated base frame. Universal machine for confectionery and rapid interchangeable for different sizes of sweet or style of wrap, primarily used for twist wrapping lollipops or similar tablets. Change parts required to accommodate different sizes. OAD: 48" L x 48" W 57" H
