Multibeam Echo Sounder Explained | Beamforming, Swath Width, Beam Steering & Survey Tips

Dive deep into the world of multibeam echo sounders and discover how modern sonar systems revolutionize seabed mapping, pipeline inspection, and hydrographic surveys. This video breaks down the beamforming technique, beam steering, swath width calculation, and data point density—all in clear, practical language. 🔍 What You’ll Learn: How multibeam sonar uses beamforming to create narrow beams from a single pulse Why multibeam systems transmit one fan-shaped pulse—not multiple beams How digital signal processing divides echoes into 256 or 512 beams The difference between single beam and multibeam depth accuracy Beam steering techniques: phase shifting, time delays, amplitude weighting Maximum steering angles and frequency effects How many depth points are recorded per ping (including dual swath mode) Swath angle ranges for shallow and deep water systems How to calculate swath width using trigonometry Practical survey planning tips for accurate seabed coverage 📊 Ideal for: Offshore surveyors Hydrographers and marine scientists Students in geospatial and ocean engineering Dredging and pipeline inspection teams Anyone curious about sonar technology 🎓 Bonus Insight: Learn how sonar geometry affects depth accuracy and coverage. 📌 Support the Channel: ✅ Like & Subscribe ✅ Join as a Member for exclusive videos (LBL, pipeline, jacket installation & more) ✅ Send a Super Thanks or buy me a coffee if you found this helpful! #MultibeamSonar #EchoSounder #HydrographicSurvey #Beamforming #SonarTechnology #Bathymetry #MarineGeospatial #OffshoreSurvey #BeamSteering #SwathWidth #SonarBasics #GeophysicalSurvey #UnderwaterMapping #SeabedMapping #DualSwath #SonarExplained You can find part 1 here -    • Single beam & Multibeam Echosounder Detail...   I am grateful to Marshall Bruner    / @marshallbrunerrf   for his valuable You tube video. Important Resources You should watch    • An introduction to Beamforming      • How to Control a Phased Array Antenna Patt...      • Phased Arrays - Steering and the Antenna P...      • What Are Phased Arrays?   Buy me a coffee if you learned something new today https://buymeacoffee.com/jaom Join this channel to get access to exclusive offshore survey videos:    / @offshoresurveys
