Single Acting Reciprocating Pump

Reciprocating pump: If the mechanical energy is converted into hydraulic energy by sucking the liquid into a cylinder in which a piston is reciprocating, which exerts the thrust on the liquid and increases its hydraulic energy is know as reciprocating pump.A reciprocating pump is a positive plunger pump. It is often used where relatively small quantity of liquid is to be handled and where delivery pressure is quite large. Reciprocating pump consists of following parts. 1. A cylinder with a piston 5. suction pipe 2. piston rod 6. delivery pipe 3. connecting rod 7. suction valve 4. crank 8. delivery valve
