Sleeve replacement for AKO pinch valve (pneumatic), VMC series, type M, DN10, DN15, DN20, and DN25

Sleeve replacement (assembly instructions) for pinch valves of the VMC series, type M, nominal sizes: DN10, DN15, DN20, and DN25. How do I replace a bladder for a pinch valve? You will be shown, step by step, how to remove the old sleeve from the pinch valve body and replace it with a new one. This is demonstrated using a valve with a threaded spigot connection (type M). Any customer can change the sleeve on site without any great effort needed, making the pinch valve ready to use again in just a few minutes. Further information and 3D data for the air operated pinch valve VMC series, type M, can be found at https://www.pinch-valve.com/products/... More information about pinch valves and other ranges and products from AKO Armaturen & Separationstechnik GmbH can be found on our website at: https://www.pinch-valve.com/ ------- Do you have any questions or suggestions? Please get in touch with us; we look forward to your enquiry: Mail: ako@pinch-valve.com
