Prototyping & Heavy Steel Processing Lot 400 - 1997 FADAL VMC 5020AHT, CNC VERTICAL MACHINING CENTER

1997 FADAL VMC 5020AHT, CNC VERTICAL MACHINING CENTER S/N 9709037 SPECIFICATIONS GENERAL FLOOR TO TABLE SURFACE: 35" MACHINE WIDTH X DEPTH: 116" W X 87" D MACHINE HEIGHT: 104" MACHINE WEIGHT: 11,500 LBS. POWER ON: 32415:04:22 RUNNING: 28318:07:52 TABLE SIZE: 20" X 56.75" T-SLOTS (NO. X WIDTH X SPAN): 5 X .687""X 3.75" CUTTING FEED RATE (X/Y/Z): .01 - 375 IPM RAPID FEED RATE: 700 IPM (X/Y) / 600 IPM (Z) MAXIMUM WEIGHT ON TABLE: 1,600 LBS. LONGITUDINAL (X AXIS): 50" CROSS (Y AXIS): 20" VERTICAL (Z AXIS): 28" SPINDLE NOSE TO TABLE: 4" - 32" SPINDLE CENTER TO COLUMN: 20" ACCURACY POSITIONING: ± .0002" (@ 68 F) REPEATABILITY: ± .0001" (@ 68 F) SPINDLE DRIVE SYSTEM WYE/DELTA: 22.5 HP* 16.8 KW SPEED: 150 - 7,500 RPM ORIENTATION: ELECTROMECHANICAL TAPER: NO. CAT40 POWER THREE PHASE: 190-510 VAC TOOLS ATC, NUMBER OF TOOLS: 21 ATC, TOOLS SELECTION: RANDOM BI-DIRECTIONAL MAX. TOOL DIAMETER: 3"" (W/O ADJACENT TOOLS 6"") MAX. TOOL LENGTH: 15"" MAX. TOOL WEIGHT: 15 LB. OPTIONS INSTALLED MEMORY EXPANSION 166K HIGH TORQUE SCALES ( X,Y&Z) 32 MP PENDANT 1000 R.P.S EXTENDED Z AXIS 28" SPINDLE NOSE TO TABLE 4" - 32"
