Create Boring Point Label Style in Civil 3D

The process of creating and manipulating point styles and point label styles is explained, focusing on customizing these elements for a rock surface project. Initially, the default styles display an X symbol representing boring hole locations, along with point number, northing, elevation, and description. The goal is to adjust the label to appear in the upper left corner as a symbol. By accessing the properties of the boring rock data point group, users can change the default styles to a pre-set point style, such as 'benchmark,' which can be adapted for boring holes. The process involves copying the current selection, renaming it to 'borings,' and ensuring it adheres to National CAD standards by creating a new layer named 'B-BOR' or 'B-HOLE.' The text color and other settings can be adjusted as needed. The description-only label style is chosen, and its position is set to the top left of the symbol. This customization allows for a clear representation of boring holes, facilitating the subsequent creation of a rock surface to be used in data shortcuts and design. The explanation is part of a training session, demonstrating how to leverage a dataset for practical application.
