AutoCAD "BrkList" Lisp Break (with at multiple points specified Stationing).

In this Video Tutorial of Auto-CAD, You have a list of stations (distances from start) and you want to "BREAK" a selected curve multiple times at the listed points. You can use the #BrkList utility. BrkList can be used as a generalised (non-linear) MEASURE command. The "BrkList" command prompts for a list of stations (distances measured from start) and then performs multiple Breaks on a selected curve in the specified points (stations). It also places point entities at the break points. The list of stations can be entered either as a comma delimited sorted list - e.g. 100,150.2,324.86,551 or read-in the list from a text file (each station on a single line) which can be exported e.g. as a #csvfilefromExcel (a result of a calculation). Supported object types: LINE, ARC, POLYLINE, LWPOLYLINE, 3DPOLYLINE, SPLINE, ELLIPSE & HELIX Download Link. https://www.cadforum.cz/en/qaID.asp?t... 00:00 intro 00:44 Draw poly, Arc, Spline, Elips and Helix 02:42 Load Vlx Lisp 03:00 Arc Break With Specify Distance 04:33 Break polyline 05:48 Break point on Spline 06:32 Line break with Specify Station 07:11 Helix break with Exact Length 08:26 Elips Break with Specify Parameter 10:26 break Station from Excel CSV and TXT File
