MORI SEIKI CL 20A CNC TURNING CENTER W/ FANUC Control

Please Call us at 909-919-9600 or Visit us at http://www.MachineStation.us for more details. , MachineStation, 4590 Eucalyptus Ave, Chino, CA 91710 MachineStation| 4590 Eucalyptus Ave. Chino, CA 91710 ----------------------------------- Make: Mori Seiki Model No.: CL 20A Serial No.: 1077 Year of Manufacture: 1994 Condition: Excellent Comes with All Original Manuals All specifications are approximations, and are subject to verification. ------------------------------------------------------- Features: MF-T8 (Fanuc 18T) CNC Control Kitagawa 8" B-208 Hydraulic Chuck Tool Pre-setter Coolant System Spindle Orientation Barfeed Interface Parts Catcher RS-232 ports 10 Station Automatic Turret Chip Conveyor Specifications: Capacity: Max Turning Diameter: 12.2" Max Turning Length: 13.3" Max Bar Capacity: 2.0" Swing Over Cross Slide: 14.9" Swing Over Bed: 18.5" X Axis Travel: 7.5" Z AXis Travel: 14.60" Rapid Traverse X Axis: 590 IPM Rapid Traverse Z Axis: 787 IPM Spindle Nose: A2-6 Spindle Bore: 2.4" Spindle Speed: 40 - 4,000 RPM Spindle Motor: 7.5kw Turret Capacity: 10 Stations Turret Index Time: 0.6 Second General: Power: 220v / 3-Phase Overall Dimensions: 111" x 63" x 68" High Overall Dimensions: 73" x 63" x 68" High (w/o Chip Conveyor) Weight: 5700 lbs
